Customized Flange Types Surface Mount Ntc Temperature Sensor

Basic Info.

Model NO.	MFP-2 Series
Measuring Medium	Temperature
IP Rating	IP67
Certification	ISO
Customized	Customized
Stripping	10mm
Wire	UL4411 22AWG Black 87mm
Transport Package	Natural Export Packing
Specification	Shell: RNB5.5-8
Trademark	Focusens
Origin	Hefei, Anhui, China
HS Code	9025900090
Production Capacity	50, 000 PCS Per Month

Product Description

Specifications:NTC Temperature sensor is connected by a high-precision, high reliability NTC thermistor and PVC wire, Teflon wire or other wire . With the shape of insulation, thermal, waterproof material packaged as required.Easy to install and control temperature. NTC temperature sensors Parameter:1. Products name: temperature sensor2. R25: 5k/ 10 k / 50 k / 100 k / 150 k / 200 k300K 500K 1000K etc.3. Resistance accuracy: + / - -1%,2% / 3% / 5%4. Woking temperature: -30°C ~ + 220°C -50°C -500°C 1000°C5. B25/50: 3100,3950,3380,3100,3950,4000,4250,4500,45006. Test accuracy : + / - -1% / 2% ±3 ±57. Terminal: customized
Product Features:
1, the heating thermostat temperature sensor
2, wide operating temperature range, good stability and reliability.
3, easy to install and operate the seal can be done according to the environment
4, low-temperature correction, accurate measurement
5, point matching or interchangeable tolerance
6, lead wire specified by the customer may terminate dock or connector
Applications:
1.Air conditioner (heat and cool) and related equipment.2.Temperature measurement and controls thermal protection circuits in various family appliances, such as air conditioner, refrigerator, electromagnetic oven, bread toaster, bake oven, electric roaster, microwave oven, electric fan, soybean milk maker, electric water heater, rice cooker, sterilizing cabinet, water dispenser and lighting appliances.3.Temperature measurement and control circuit in the equipment for industrial and agricultural, medical, meteorological purpose, environmental protection and food processingAutomatic office appliances.Other Prodcuts:
